10 Port Ethercon Managed Switch 8 x 1Gbit Ports + 2 x Optical/ Ethercon Trunk Ports, 2 x Powercon in

Description:

Kudos Technology provides Ruggedised Network switching for the live events and AV Installation Industries. Powered by Cisco 300 series managed switches, the RDG-1M10-01 provides proven robust technology in a format suitable for the fast-paced target industries.

Features nine Neutrik EtherCon on the rear and one on the front. Cabling is contained to within the rack reducing risks of cable damage.

Options for Single/Multi-Mode Optical connectivity with choices of OpticalCon, HMA or standard LC connections on either the front or rear of the switch. Link/ activity LED’s and 1 Gigabit LED's are provided front and rear to improve visibility of the switches operation. Dual Power Supplies are installed with Supply health indication.

Features:

- Configured ready for media streaming applications

- Dual redundant Power Supplies

- Rugged EtherCon Connectivity

- LED indication both Front and Rear

- Optical connectivity mounted either front or rear.

Specification:

- 2 x PowerCon Inputs

- 10 x 1000Mps EtherCon Ports

- Layer 2 Switching including Spanning Tree Protocol, Port Grouping, VLAN and QoS.

- Layer 3 Including IPv4 Routing and DHCP Server

Options:

- Neutrik OpticalCon

- Single or Multi mode mounting front or rear.

- HMA Optical outputs mounting Front or Rear

- Single or Multimode Standard LC Connection
